Digital Printing Steamer STM-H Series
Features
Ø The steamer is encircled hanging with no tension traction. It’s suitable for steaming of all kind of cloth which including elastic knitting cloth, etc. inside of steamer, the cloth façade and the roller is untouched form each other, to ensure the cleanness of the cloth.
Ø A wide range of specifications of containing and fabric width are available as well as customized product.
Ø Temperature range is between 102℃～190℃， suitable for all kinds of steaming process.
Ø Small and exquisite, economized space
Ø Low steam wastages and cost
Ø Electric heating. No need for oil burning boiler or boiled oil. Convenient.
Ø Suitable for a daily production under 10,000m.
Ø It is the best for table printing, digital inkjet printing and sample printing before mass production.
|
|
unit
|
STM-H Series
|
|
Liner fabric capacity
|
Meter
|
20
|
40
|
60
|
|
Optical width of cloth
|
mm
|
1800/2800/3200
|
|
Dwell Time
|
min
|
4-40
|
4-40
|
4-40
|
|
Low Steaming Temperature
|
℃
|
102-110
|
|
High Steaming Temperature
|
℃
|
150-190
|
|
Consumption of Steam
|
Kg/hr
|
50
|
75
|
100
|
|
Power
|
kw
|
24
|
36
|
48
|
|
Outside Dimension - Length
|
mm
|
3000
|
3900
|
4400
|
|
Outside Dimension- Width
|
mm
|
Optional of Cloth + 1100
|
|
Outside Dimension- Height
|
mm
|
2350
|
2500
|
2700
|
|
|
|
|
|
|
|
|
|
|
|
|
